The remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or for example the engine run/stop switch.Â
All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output Current
An unlimited number of units can be connected in parallel. Â
High Temperature ProtectedÂ
The output current will reduce at high ambient temperatures. Â
IP43 ProtectionÂ
When installed with the screw terminals oriented downward. Â
Screw TerminalsÂ
No special tools are needed for installation. Â
Input Fuse (not replaceable)Â
On 12 V and 24 V input models only. Â
Adjustable Output VoltageÂ
Not intended for battery charging (consider using an Orion-Tr Smart for battery charging).
Specifications:
Input Voltage Range: 16-35 V
Under Voltage Shut Down: 14 V
Under Voltage Restart: 15 V
Nominal Output Voltage: 24.2 V
Output Voltage Adjust Range: 20-30 V
Output Voltage Tolerance: +/- 0,2 V
Output Noise: 2 mV rms
Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 12 A
Maximum Output Current (10 S) at Nominal Output Voltage: 15 A
Short Circuit Output Current: 30 A
Cont. Output Power at 25 Degrees C: 320 W
Cont. Output Power at 40 Degrees C: 280 W
Efficiency: 89 %
No Load Input Current (2): < 80 mAÂ
Galvanic Isolation: 200 VDC between input, output, and case
Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C)
Humidity: Max. 95 % non-condensing
DC Connection: Screw terminals
Maximum Cable Cross-Section: 16 mm² AWG6
Weight: 1.3 kg (3 lb)
Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
Safety Standards: EN 60950
Immunity Standards: EN 61000-6-3, EN 61000-6-1, EN 55014-2
