Simrad SS75M 20DEG 80-130KHZ 9-PIN Thru Hull

$879.00
by Simrad

Simrad SS75M 20 Degree Tilt

Model: 000-13910-001
  • CHIRP transducers enable bottom detection with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures.
  • Calculates how deep the water is, so that you can avoid running aground, whilst also incorporating a temperature sensor for accurate water temperature readings.
  • CHIRP range is 80kHz-130kHz for good target detail in shallow water and excellent bottom tracking in deep water.
  • Provides extremely accurate data.
  • The 20° tilt is ideal for boats with a 16° to 24° hull deadrise.
  • The low profile housing minimizes drag with just 5mm extending outside of the hull.
  • Easily connect to NSSevo3

The SS75M is a bronze, thru-hull, tilted, medium-frequency (80-130kHz), depth and temperature transducer. The ceramic element is tilted for built-in deadrise compensation, giving excellent echo returns for more accurate depth readings.

Specifications
Frequency Medium CHIRP (80-130kHz)
Power rating 600 watts
Speed sensor No
Temperature sensor Yes
Mounting style Stainless Thru-hull
Elements 1
Beamwidth @ -3db 24° to 16°
Cable length 10 meter
