| Temperature range |
-15 to +55°C (+5 to +131°F) |
| Waterproof |
IPX7 |
| Normal Working Voltage |
+13.6 V DC |
| Minimum operating Voltage |
≤10 V DC |
| Low battery detect Voltage |
10.5 ± 0.5 V DC |
| Over Voltage Protection |
>15.8 ± 0.5 V DC |
| Hailer Audio Power Out |
30 W |
| Current Drain RX Max Audio Power |
≤1.5 A |
| Current Drain Stand-By RX |
≤0.45 A |
| Current Drain At 12V DC : Hi Power TX |
≤6 A |
| Current Drain At 12V DC : Lo Power TX |
≤1.5 A |
| Frequency Range: Transmit |
156.025 ~ 157.425 MHz |
| Frequency Range: Receive |
156.050 ~ 163.275 MHz |
| Channels |
PLL |
| Modulation |
FM(16KOG3E) DSC(16K0G2B) |
| Channel Spacing |
25 KHz |
| Frequency Stability |
± 5 PPM |
| Digital Selectivity Calling (DSC) |
Class D |
| LCD Display |
FSTN 256x160 Pixels |
| AIS Max Targets |
150 |
| Intermediate Frequency : 1st |
38.85/21.7 MHz |
| Intermediate Frequency : 2nd |
450 KHz |
| Sensitivity : 12dB SINAD |
≤-6 dBuV(EMF) |
| Squelch Sensitivity: at tight |
≤ 6 dBuV(EMF) |
| Spurious Response Rejection Ratio |
≥70 Db |
| Adjacent Channel Selectivity |
≥70 dB |
| Intermodulation Response |
≥68 dB |
| S/N at 3KHz Dev. |
≥40 dB |
| Audio Output Power At THD 10% |
≥2.5 W |
| Audio Distortion |
≤10 % |
| Audio Response |
+1 to -3dB of 6dB/octave from 300hz to 3kHz |
| Current Drain Max Audio Power |
≤1.5 A |
| Current Drain Stand-By |
≤0.45 A |
| 2ND RX Sensitivity For 12dB SINAD |
≤ 0 dBuV(EMF) |
| 2ND RX bit error ratio@-107dBm |
≤ 10-2 |
| Frequency error |
≤±1.5KHz KHz |
| RF Power : Hi |
23 ± 2 W |
| RF Power : Lo |
0.8 ± 0.2 W |
| Maximum Deviation |
≤± 5 KHz |
| S/N at 3KHz Dev. |
≥40 dB |
| Modulation Distortion |
±3KHz ≤10 % |
| Audio Response at 1KHz Dev. |
+1 to -3dB of 6dB/octave from 300hz to 3KHz dB |
| Spurious/Harmonic Emissions: Hi/LO |
≤0.25 uW |
| Modulation Sensitivity |
≤15 mV |
| DSC TX deviation at 1.3K |
2.6±0.26 KHz |
| DSC TX deviation at 2.1K |
4.2±0.42 KHz |
| ATIS TX deviation at 1.3 KHz |
1.3±0.13 KHz |
| ATIS TX deviation at 2.1 KHz |
2.1±0.21 KHz |
