| GNSS Constellations |
GPS, GLONASS, Galileo, BeiDou, QZSS |
| SBAS tracking |
2-channel, parallel tracking (WAAS, EGNOS, |
| Position accuracy (no SBAS) |
1.5 m RMS (no SBAS) |
| Heading accuracy, static/dynamic (RMS) |
<2° (RMS) |
| Heading dead reckoning (DR) deviation per minute |
2°/min (up to 3 minutes) |
| Pitch/roll accuracy, static/dynamic (RMS) |
1.5° (RMS) |
| Heading accuracy, magnetic post 3 min DR |
<±3° TRUE |
| Heave accuracy, dynamic (RMS) |
30cm |
| Update rate |
10Hz |
| Rate of turn |
500°/s maximum |
| Time to position fix |
25 s typical |
| Time to Heading Fix (GNSS) |
10 s typical (after you have valid position) |
| Compass safe distance |
0.5 m |
| Power |
| Input voltage |
9—16 V DC |
| Power consumption |
1.6 W (multi-GNSS, typical continuous draw at 12 V) |
| Load equivalency number (LEN) |
3 |
| Power isolation |
Isolated to enclosure |
| Reverse polarity protection |
Yes |
| Connector |
NMEA 2000® Micro C |
| Other |
| Weight (no mount) |
0.85 kg (1.87 lb) |
| Operating temperature |
—25°C to + 70°C (—13°F to +158°F) |
| Enclosure |
IPX6 and IPX7 |
