Simrad AC70 Autopilot Computer
Model: 000-10186-001
AC70 Drive computer for rudder or propeller (i.e. Voith Schneider) for reversible motor or galvanic non-isolated solenoids.
Specifications
| Power |
12/24 V in |
| DRIVE |
Output for Motor or solenoid command |
| DRIVE ENGAGE |
Output for clutch/bypass valve or automode signal for oil flow valve etc |
| ALARM |
Output for external alarm buzzer |
| NMEA 0183 |
in/out for IEC 61162-1, -2 and NMEA 0183 |
| RUDDER |
Input for frequency rudder feedback |
| REMOTE |
Input for NFU steering lever |
| MODE |
Input for external mode selector |
| SIMNET |
Connection to CAN network |
What's in the Box:
- AC70 Course Computer
- N2K Power Cable including 120 ohm Terminator
- N2K Terminator Male
- N2K Cable - 0.6m (2ft)
- N2K T-Joiner
