Display |
Type |
Color TFT multi touch In-Plane Switching (IPS) LCD |
Screen Size |
12.1" Wide |
Screen Resolution |
WXGA 1280 x 800 |
Screen Brightnes |
900 cd/m2 (typical) |
Display Colors |
16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder) |
Language |
Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish GPS/WAAS |
GPS/WAAS |
Receiver Type |
GPS: 72 channels, SBAS: 1 channel (C/A mode, WAAS |
Receiving Frequency |
L1 (1575.42 MHz) |
Time to First Fix |
100 s (cold start) |
Accuracy |
10 m (GPS), 7 m (MSAS), 3 m (WAAS) |
Position Update Interval |
0.1 s (10Hz) |
CHART PLOTTER |
Cartography |
MapMedia mm3d chart (C-MAP/Navionics/NOAA) |
Memory Capacity |
30,000 user points, 30,000 points for ship's tracks, 200 planned routes (500 points per route) |
Alarms |
Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge*, Wind Alarm*, Boundary Alarm (*external data required) |
Radar |
Display Modes |
Head-up*, North-up *Heading input required. |
Echo Trail |
Interval: 15 s, 30 s, 1 min, 3 mins, 6 mins, 15 mins, 30 mins and continuous |
Target Tracking |
30 ARPA Targets |
Radar Alarms |
Guard Zone, CPA/TCPA, Trigger, Video, Azimuth, Heading Line |
FISH FINDER |
Transmit Frequency |
CW: 50/200kHz CHIRP: 40kHz to 225kHz |
Transducer |
300/600 W or 1 kW* *Matching box MB1100 required for some FURUNO transducers |
Display Range |
2 to 1,200 m, shift: 0 to 1,200 m |
Extension Mode |
ACCU-FISH™, A-Scope, Auto (Fishing/Cruising), RezBoostTM, Bottom Discrimination, TruEcho CHIRPTM |
Picture Advance |
8 steps: x4, x2, x1, 1/2, 1/4, 1/8, 1/16, stop |
Fish Finder Alarms (option) |
School of fish, School of fish for bottom lock |
INTERFACE |
CAN bus/NMEA2000 |
1 Port |
NMEA0183 |
1 Serial Output Port |
LAN |
2 Ports (100 BASE-TX) |
USB |
1 Port (USB2.0) for touch monitor and control unit: |
Video I/O |
Input: 2 Ports (NTSC/PAL) Output: 1 Port (HDMI 720p) |
AUX I/O |
2 Ports (Event Switch and External Power Switch) and 1 Port Buzzer Output |
SD Card Slot |
1 Micro SD Card Slot (Micro SDXC, rear), 2 Slots Card Unit: Model SDU-001 (option) |
Wireless LAN |
IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max |
Transducer |
1 Port, 1 Port — DI-FFAMP |
ENVIRONMENT |
ENVIRONMENT |
-15°C to +55°C |
Relative Humidity |
93% or less at +40° C |
Waterproofing |
IP56 |
POWER |
Voltage |
12-24 VDC |
Current draw |
2.3 - 1.2 A |
