Blue Sea Triple Battery Bank Management Panel

$617.17
by Blue Sea Systems
Type: Battery - Switch

Blue Sea Systems Triple Battery Bank Management Panel

Model: 8693-BSS
  • Isolates the Engine circuit from the House circuit
  • Allows emergency cross connect between isolated battery banks
  • Protects electronics from sags and spikes caused by engine cranking
Specifications
Positions 11
Nominal Voltage 12V DC, 24V DC
Maximum Voltage 32V DC
Continuous Rating 350A
Intermittent Rating 525A (5 min)
Cranking Rating 10 sec 1000A
Cranking Rating 1 min 750A
Height 8.00in (203.2 mm)
Depth 3.50in (88.9 mm)
Weight 4.42lb (2 kg)
