Blue Sea Traditional Metal Dual Bank Battery Management Panel

$330.94
by Blue Sea Systems
Type: Battery - Switch

Blue Sea Traditional Metal Dual Bank Battery Management Panel

Model: 8280-BSS
  • Isolates the Engine circuit from the House circuit
  • Allows emergency cross connect between isolated battery banks
  • Protects electronics from sags and spikes caused by engine cranking
Specifications
Maximum Voltage 48V DC
Continuous Rating 300A
Intermittent Rating 500A (5 min)
Cranking Rating 10 sec 1500A
Cranking Rating 1 min 775A
Height 7.50in (190.5 mm)
Width 6.25in (158.75 mm)
Depth 2.25in (57.15 mm)
Weight 3.20lb (1.45 kg)

What's in the Box:
  • 8280 Panel
  • Instructions
