Egis XD Triple 2 Pole XD Flex 2 RelayRelay wKnobs 87301505

Egis XD Triple - 2 Pole XD Flex 2 - Relay/Relay w/Knobs [8730-1505]

$276.30
by Egis Mobile Electric
Type: Accessories

XD Triple - 2 Pole XD Flex 2 - Relay/Relay with Knobs

Features:

  • Up to 500 Amp Continuous Capability Per Relay / Extremely Compact Footprint
  • Meets Aluminum Hull and US Coast Guard Safety Requirements For Isolated Switching of Both Positive and Ground Leads.
  • Multiple Voltage Capability For Multi Voltage/ Multi Battery Chemistry Battery Applications With 12 & 24V Switching Capability in One Device.
  • Remote ON/OFF/Auto Inputs allow forced close or open, or allow automatic operation based on Voltage Sensing
  • LED Indicator Provides Helpful Diagnostics
  • Flexible Functionality via Dip Switches: Low Voltage OFF Set-Point, Delay Off Time, and Voltage Differential for Warning Signal

Specifications:

  • Type: Electric
  • Box Dimensions: 3"H x 6"W x 8"L WT: 2.25 lbs
  • UPC: 850053879500

Brochure (pdf)
